Viper 10/4 Royal Cable, Generator Wire, Per Foot
- Mfg.#
- 55812604
- Sku#
- 9751975
- Good Tensile Strength, Elongation and Aging Characteristics
- Black Jacket.
- Provides Premium Oil Resistance, Water Resistant and High Flexibility
* Estimated stock levels as of Tue, Mar 31, 2026. All items subject to prior sale. Prices may vary between stores and online. Please call ahead to confirm availability of items marked as Limited Stock.
Description
Southwire Type SJOOW Flexible Cords are permitted for use as specified by Article 400 and related articles of the 2014 National Electrical Code. Some typical applications for Type SJOOW Cords include wiring for portable tools, portable appliances,equipment, small motors and associated machinery. Southwire Type SJOOW Flexible Cords are manufactured using bare flexible stranded Class K copper conductors, with a heat, moisture and oil resistant EPDM rubber insulation. The insulated conductors are cabled with wax paper fillers, with a tissue-paper separator wrapped around the assembly to promote easier removal of the jacket. A heat, moisture and oil resistant flexible CPE jacket is extruded over the assembly to complete the construction. Sizes 18 through 10 AWG fully annealed stranded bare copper per ASTM B-174. Some sizes may be subject to minimum order quantity.
Specifications
General
| Allowable Ampacities | 25-Jan |
|---|---|
| Application | For motor leads, portable lights, battery chargers, portable stage lights and portable machinery |
| Color | Black |
| Conductor Material | ASTM B-174 Annealed Bare Copper |
| Conductor Size | 10 AWG |
| Indoor/Outdoor | Indoor/Outdoor |
| Insulation | 0.045 in thickness |
| Insulation Material | EPDM Rubber |
| Jacket Material | CPE |
| Jacket Thickness | 0.060 in |
| Resistance | Premium Oil Resistance, Water Resistant, Abrasion Resistance |
| Strand Size | 104/30 |
| Temperature Rating | -40 TO 90-Degree C |
| Type | SJOOW |
| Voltage Rating | 300V |
Dimensions
| Length | 1 ft |
|---|---|
| Outside Diameter | 0.64 in |
| Size | 4-Oct |
| Weight | 305 lb/1000 ft |
Label Information
| Certification, Codes, Standards | Csa certified, rohs compliant, msha approved for flame resistance in mining applications, class K stranding per ASTM B 174; UL 62, CSA 22.2 Approval |
|---|
