200-Amp Homeline™ Load Center
- Mfg.#
- HOM816M200PFTRB
- Sku#
- 5751656
* Estimated stock levels as of Thu, Feb 26, 2026. All items subject to prior sale. Prices may vary between stores and online. Please call ahead to confirm availability of items marked as Limited Stock.
Description
The Homeline™ load center offer features Homeline™ circuit breakers, ground fault circuit breakers and arc fault interrupters. Homeline™ load centers enable the use of a full complement of accessories. Systems are single phase and are rated for indoor use or are rain proof. Homeline™ load centers are designed for residential and industrial use to protect electrical systems, equipment and people. This Homeline™ load center has a two pole plug on neutral main supply circuit breaker that is rated at 200A 120/240 VAC single phase. Homeline™ load center provides a 22 kA breaking capacity. This system provides 8 spaces in a NEMA 3R rain proof enclosure. The electrical connections are feed thru lugs. The lugs will accept a wire range of 4 AWG to 250 kcmil copper or aluminum wire. This Homeline™ load center has a height of 29.84 inches, a width of 14.76 inches, and depth of 4.52 inches. Homeline™ load centers are UL Listed.
Specifications
General
| Amps | 200 |
|---|---|
| Bus Bar Material | Tin plated aluminium busbar |
| Cover Type | Surface cover |
| Electrical Connection | Feed-thru lugs |
| Enclosure Material | Welded galvannealed steel |
| Enclosure Rating | NEMA 3R outdoor |
| Finish | Surface: Baked enamel Gray |
| Grounding Type | Grounding bar (ordered separately) |
| Includes | Circuit-breaker 1) 2P 200 A 120/240 V AC main supply ready assembled |
| Indoor/Outdoor | Outdoor |
| Load Centers & Distribution Type | Main Lug Load Center |
| Maximum Single Pole Circuits | 16 |
| Maximum Tandem Circuits | 8 |
| Misc | Max Short Circuit Current Rating: 22 kA; Ambient Air Temperature for Operation: 23 °F (-5 °C), 104 °F (40 °C) |
| Number of Circuits | 16 |
| Number of Phases | 1 |
| Spaces | 8 |
| Type | Main Lug Load Center |
| Volts | 120/240 |
| Wire Size | AWG 4...250 kcmil copper or aluminium |
| Wiring Configuration | 3-wire |
Dimensions
| Depth | 4.53 in (115 mm) |
|---|---|
| Height | 29.84 in (758 mm) |
| Width | 14.76 in (375 mm) |
Manufacturing Details
The following information is subject to change without notice
| Country of Origin | US |
|---|---|
| Prop 65 Warning |
WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
|
| Shop USA | Yes |
Label Information
| Certification, Codes, Standards | UL listed file E-6294 |
|---|
